Antec P20E Gaming Case

Simple Assembly & Superior Cooling
Antec Performance Series P20C White adopts a unique metal design, providing a massive airflow path. With the full-size dust filter, the P20C White can reach the balance between cooling and dust prevention. The pin-type metal front panel is effortlessly removable, and the clip-on dust filter makes cleaning easy. The well-designed styling will give you a remarkable PC showcase.
Full-Size Clip-On Dust Filter at the Front
Magnetic Dust Filter at the Top
Pull-Out Dust Filter at the Bottom

3 x 120mm PWM Fans Included
Pre-installed fans at the front provide massive airflow, and the PWM function can easily reach the balance between cooling and silence.
The included 1 to 4 fan splitter cable makes cable management easy.

Type-C 3.2 Gen 2 Ready
Built-in Type-C 3.2 Gen 2 port provides transfer speeds up to 10 Gbps.
Power
Reset
HD-AUDIO
MIC
USB 3.0 *2
Type-C 3.2 Gen 2

High flexibility for Expansion
Features an extensive interior and powerful compatibility. Supports 2 x 360mm radiators at the front and the top simultaneously.

Supports Vertical GPU Installation
Ready to provide users with a more flexible layout through the 7 reusable PCI-E slots for vertical GPU installation.

Dual CPU Motherboard Support
Supports dual CPU motherboards with a width of up to 330mm, reflecting the upgrade and evolution of compatibility.

Building a Clean PC Is Within Easy Reach
Well-designed cable routing makes wiring easy and simple. The cable channels with a cutout on top for stable routing.

9 Fans Simultaneously
3 x 120mm fans and a 360mm radiator can be installed inside the interior at the front. Plus 3 x 120mm fans outside the interior for outstanding cooling. Supports up to 9 x 120mm fans & 360mm radiators at the front and top simultaneously.

Easy Installation
Fits up to 4 drive devices. 2 HDD & SSD compatible hard drive bays; 2 SSD hard drive bays.
Snap-in 2.5" drive device for easy mounting.
Removable hard drive cage.
Tool-free 3.5" drive tray.

Features

1. Featuring a large metal perforation design and a full-face dust filter, it maintains a large airflow while effectively preventing dust accumulation
2.4mm panoramic side glass panel, capable of displaying components.
3. Supports dual-CPU E-ATX (maximum length 330mm) motherboards, increasing the variety of motherboard options.
4. The top and front sections can simultaneously support 360mm water cooling radiators, with a minimum length of 403mm for both.
5.Includes a fan 1 to 4-point cable for easy cable management.
6.The front panel comes standard with three 120mm PWM white-framed, white-blade fans, which effectively regulate CPU temperature and fan speed, and significantly reduce fan noise.
7. The power supply uses a rear-insertion design and comes with two anti-slip pads for easy plugging and unplugging.
8.The power supply compartment features a honeycomb-style vent design, allowing for easy installation of two 120mm fans to accelerate graphics card cooling.
9. The back of the side panel uses lock-on screws, which will remain attached to the side panel even after the screws are loosened, so there's no need to worry about the screws being lost after removal.
10. Seven reusable PCIe brackets, fully compatible with most commercially available vertical adapters.
11. Seven reusable PCIe brackets, fully compatible with most commercially available vertical adapters.
12. Includes 8 white cable guides (tethering rubber rings) + 3 extra cable ties
13.White magnetic dust filter at the top + white plastic snap-on dust filter at the front + white pull-out plastic filter at the bottom
14.Removable 3.5” HDD Holder
15. Includes a white graphics card bracket, which allows for adjustment of the graphics card's support position to prevent deformation and damage caused by the graphics card sagging.

Specifications

Case Specification
Dimensions469 x 220 x 490mm (DWH)
Form FactorMid Tower
MaterialsSteel + Plastic
Mainboard SupportE-ATX, ATX, Micro-ATX, ITX
Front Access & ControlsPower, Reset , USB 3.0 x 2, Type-C 3.2 Gen 2 x 1, MIC x 1, HD-AUDIO x 1
Side Panel4 MM Tempered Glass Side Panel

Drive Bays
Expansion Slots7
3.5" /2.5"2/2
2.5"2

Fan
Front3 x 120mm / 3 x 140mm
Top 3 x 120mm / 2 x 140mm
Power Supply Shroud 2 x 120mm
Rear1 x 120mm
Included Fan(s)Pre-installed 3 x 120mm PWM fans in front (P20C White)

Radiator Support
Front120 / 140 / 240 / 280 / 360mm
Top120 / 140 / 240 / 280 / 360mm
Rear120mm

Clearance
Max GPU Length= 375mm
Max CPU Cooler Height= 170mm
Max PSU Length(Include cable) = 205mm(with HDD)
(Include cable) = 410mm(without HDD)

Miscellaneous
Dust FilterFront / Top / Bottom
Net Weight8.1 Kg(P20C White) / 8.3 Kg(P20C White Elite)
Gross Weight9.32 Kg(P20C White) / 9.52 Kg(P20C White Elite)
Warranty2 Years

Brand: ANTEC

Category: Cases

EAN: 0761345801089

Manufacturer Code: 0-761345-80108-9

Overview

ANTEC P20CE Case, E-ATX Gaming, White, Mid Tower, 2 x USB 3.0 / Type-C 3.2 Gen 2 x 1, E-ATX, ATX, Micro-ATX, ITX is listed under manufacturer code 0-761345-80108-9. It sits within the Cases & Cooling category. DCS Components can help source this item as part of a quote-led procurement request.

Key product details

• Manufacturer code: 0-761345-80108-9
• Category: Cases & Cooling
• EAN: 0761345801089
