| Type | AV transmitter |
|---|---|
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5e, Cat6 |
| Maximum transfer distance | 100 m |
| Maximum refresh rate | 60 Hz |
| Extended display identification data (EDID) | Yes |
| LED indicators | Yes |
| Supported video modes | 1080p |
| Supported graphics resolutions | 3840 x 2160, 4096 x 2160 |
| HDCP | Yes |
| Material | Metal |
| Control type | Buttons |
| Baud rate | 19.2 Kbit/s |
| Impedance | 100 Ω |
| Daisy chain | Yes |
| Product colour | Black |
| Connectivity technology | Wired |
|---|---|
| RJ-45 output ports | 1 |
| HDMI in | 1 |
| USB ports quantity | 1 |
| USB version | 2.0 |
| USB connector type | USB Type-B |
| Audio input | 1 |
| Remote (IR) input | 1 |
| DC-in jack | Yes |
| Operating voltage (transmitter) | 5 V |
|---|---|
| Power consumption (TX) | 3.08 W |
| External power adapter | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Width | 136 mm |
|---|---|
| Depth | 101 mm |
| Height | 29.6 mm |
| Weight | 600 g |
| Quantity per pack | 1 pc(s) |
|---|---|
| Package width | 59 mm |
| Package depth | 239 mm |
| Package height | 160 mm |
| Package weight | 790 g |
| AC adapter included | Yes |
|---|---|
| Manual | Yes |
| Master (outer) case width | 250 mm |
|---|---|
| Master (outer) case length | 325 mm |
| Master (outer) case height | 175 mm |
| Master (outer) case gross weight | 4.23 kg |
| Master (outer) case net weight | 3 kg |
| Products per master (outer) case | 5 pc(s) |
VC986
874P5AA
993-001896
