Startech 1 Port Gigabit PoE+ Extender 802.3at & 802.3af - 100m (330ft) - Power over Ethernet Extender - PoE Repeater Network Extender (POEEXT1GAT) - Repeater - 1GbE - 10Base-T, 100Base-TX, 1000Base-T - up to 100 m - for P/N: ST12MHDLANU

Description

Manufacturer Code: POEEXT1GAT

Overview

Startech 1 Port Gigabit PoE+ Extender 802.3at & 802.3af - 100m (330ft) - Power over Ethernet Extender - PoE Repeater Network Extender (POEEXT1GAT) - Repeater - 1GbE - 10Base-T, 100Base-TX, 1000Base-T - up to 100 m - for P/N: ST12MHDLANU is available through DCS Components. It sits within the Networking category.

Key product details

• 100m (330ft)
• Power over Ethernet Extender
• PoE Repeater Network Extender (POEEXT1GAT)
• Repeater
• 1GbE

Procurement and setup support

Available for quote while live availability remains in stock. DCS can help with procurement, compatibility checks, configuration planning, installation support and long-term managed IT lifecycle support.

EAN: 0065030860895

Specifications

Performance

Type	Network repeater
Maximum transfer distance	100 m
Data transfer rate	2000 Mbit/s
Auto MDIX IEEE	Yes
Jumbo frames support	No
Auto-negotiation	Yes
Duplex system	Full, Half
Plug and Play	Yes
Mean time between failures (MTBF)	50000 h

Network

Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x

Ports & interfaces

Power over Ethernet (PoE) ports quantity	2

Design

Product colour	Black
Housing material	Steel
LED indicators	Activity, Link, PoE
Certification	CE, FCC, TAA, REACH

Power

AC input voltage	52 - 56 V
Power consumption (max)	3.2 W
Power over Ethernet (PoE)	Yes

Operational conditions

Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-10 - 85 °C
Operating relative humidity (H-H)	5 - 95%

Weight & dimensions

Width	69 mm
Depth	94 mm
Height	25 mm
Weight	193 g

Packaging content

Manual	Yes

Packaging data

Package width	135 mm
Package depth	205 mm
Package height	70 mm
Package weight	343 g

Certificates

Compliance certificates	RoHS

Logistics data

Harmonized System (HS) code	85176990
