Manufacturer Code: SV231TDPU34K
Overview
Startech 2 Port Triple Monitor DisplayPort KVM Switch, 4K 60Hz UHD HDR, Desktop 4K DP 1.2 KVM with 2 Port USB 3.0 Hub (5Gbps) & 4x USB 2.0 HID Ports, Audio, Hotkey Switching, TAA - Keyboard/Video/Mouse Switch - KVM / audio switch - 2 x KVM / audio - deskt is available through DCS Components. It sits within the KVM Switches, Cables & Accessories category.
Key product details
Procurement and setup support
Available for quote while live availability remains in stock. DCS can help with procurement, compatibility checks, configuration planning, installation support and long-term managed IT lifecycle support.
EAN: 0065030881784
| Number of computers controlled | 2 |
|---|---|
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| DisplayPorts quantity | 9 |
| DisplayPort version | 1.2 |
| Console ports | 3.5mm headphone, DisplayPort, USB A |
| Console USB ports quantity | 4 |
| USB hub | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 2 |
| Audio connections | Yes |
| Headphone outputs | 3 |
| DC-in jack | Yes |
| HD type | 4K Ultra HD |
|---|---|
| Maximum resolution | 3840 x 2160 pixels |
| Video bandwidth | 60 Hz |
| Scan interval | 3,8,15,30 s |
| HDCP | Yes |
| Daisy chain | No |
| Audio channels | 5.1 |
| Number of displays supported | 3 |
| Product colour | Black |
|---|---|
| Housing material | Steel |
| LED indicators | Yes |
| Push button | Yes |
| Hot keys | Yes |
| Mean time between failures (MTBF) | 156000 h |
| Certification | CE, RoHS, FCC |
| Built-in display | No |
|---|---|
| On Screen Display (OSD) | No |
| Input voltage | 100 - 240 V |
|---|---|
| Input current | 1 A |
| Output voltage | 12 V |
| Output current | 3 A |
| Power consumption (typical) | 36 W |
| Power plug type | Type M |
| Compatible power plug types | AU, EU, JP, UK, US |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Width | 160 mm |
|---|---|
| Depth | 100 mm |
| Height | 98 mm |
| Weight | 850 g |
| Package width | 238 mm |
|---|---|
| Package depth | 189 mm |
| Package height | 91 mm |
| Quick installation guide | Yes |
|---|---|
| Rubber feet | Yes |
| IP control | No |
|---|
| Harmonized System (HS) code | 85176200 |
|---|---|
| Master (outer) case width | 397 mm |
| Master (outer) case length | 317 mm |
| Master (outer) case height | 280 mm |
| Products per master (outer) case | 6 pc(s) |
