Startech 4-Port DisplayPort 1.4 KVM Switch, 8K 60Hz / 4K 144Hz, 2x USB 3.0 Ports, 4x USB 2.0 Ports, Hotkey Switching, TAA Compliant (D86A2-4-PORT-8K-KVM) - KVM / audio / USB switch - 4 x KVM / audio / USB - 1 local user - desktop - TAA Compliant

Description

Manufacturer Code: D86A2-4-PORT-8K-KVM

Overview

Startech 4-Port DisplayPort 1.4 KVM Switch, 8K 60Hz / 4K 144Hz, 2x USB 3.0 Ports, 4x USB 2.0 Ports, Hotkey Switching, TAA Compliant (D86A2-4-PORT-8K-KVM) - KVM / audio / USB switch - 4 x KVM / audio / USB - 1 local user - desktop - TAA Compliant is available through DCS Components. It sits within the KVM Switches, Cables & Accessories category.

Key product details

• KVM / audio / USB switch
• 4 x KVM / audio / USB
• 1 local user
• desktop
• TAA Compliant

Procurement and setup support

Available for quote while live availability remains in stock. DCS can help with procurement, compatibility checks, configuration planning, installation support and long-term managed IT lifecycle support.

EAN: 0065030893206

Specifications

Ports & interfaces

Number of computers controlled	4
Keyboard port type	USB
Mouse port type	USB
Video port type	DisplayPort
DisplayPorts quantity	4
DisplayPort version	1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity	4
Console ports	3.5mm headphone, DisplayPort, USB A
Console DisplayPorts ports quantity	1
USB 2.0 Type-A hub ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity	2
Audio connections	Yes
Headphone outputs	4
DC-in jack	Yes

Performance

HD type	8K Ultra HD
Maximum resolution	7680 x 4320 pixels
Data transfer rate (max)	5000 Gbit/s
Scan interval	3,8,15,30 s
High Dynamic Range (HDR) supported	Yes
HDCP	Yes
Daisy chain	No
Chipset	GL-3523
HDCP version	1.4/2.2

Design

Rack mounting	No
Product colour	Black
Housing material	Steel
LED indicators	Yes
Push button	Yes
Hot keys	Yes
Mean time between failures (MTBF)	130000 h

Display

Built-in display	No

Power

Power source	DC
Input voltage	100 - 240 V
Input current	1 A
Output voltage	12 V
Output current	3 A
Power consumption (typical)	36 W
Power plug type	Type M
Compatible power plug types	EU, JP, UK, US

Sustainability

Sustainability compliance	Yes
Compliance certificates	CE, RoHS, Trade Agreements Act (TAA)

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 85%

Weight & dimensions

Width	130 mm
Depth	220 mm
Height	44 mm
Weight	1 kg

Packaging data

Package width	409 mm
Package depth	212 mm
Package height	87 mm
Package weight	1.6 kg

Packaging content

Quick installation guide	Yes
Rubber feet	Yes

Other features

IP control	No

Logistics data

Master (outer) case width	545 mm
Master (outer) case length	427 mm
Master (outer) case height	245 mm
Products per master (outer) case	60 pc(s)
