Startech 4 Port DisplayPort KVM Switch, 4K 60Hz, Single Display, Dual Port UHD DP 1.2 USB KVM Switch with Integrated USB 2.0 Hub and Audio, Dell, HP, Apple, Lenovo, TAA Compliant - Keyboard/Video/Mouse Switch (SV431DPUA2) - KVM / audio switch - 4 x KVM / audio - 1 local user - desktop - AC 100 - 240 V

Description

Manufacturer Code: SV431DPUA2

Overview

Startech 4 Port DisplayPort KVM Switch, 4K 60Hz, Single Display, Dual Port UHD DP 1.2 USB KVM Switch with Integrated USB 2.0 Hub and Audio, Dell, HP, Apple, Lenovo, TAA Compliant - Keyboard/Video/Mouse Switch (SV431DPUA2) - KVM / audio switch - 4 x KVM / is available through DCS Components. It sits within the KVM Switches, Cables & Accessories category.

Key product details

• Keyboard/Video/Mouse Switch (SV431DPUA2)
• KVM / audio switch
• 4 x KVM /

Procurement and setup support

Available for quote while live availability remains in stock. DCS can help with procurement, compatibility checks, configuration planning, installation support and long-term managed IT lifecycle support.

EAN: 0065030826372

Specifications

Ports & interfaces

Number of computers controlled	4
Keyboard port type	USB
Mouse port type	USB
Video port type	DisplayPort
DisplayPorts quantity	5
USB 2.0 Type-B ports quantity	4
Console ports	3.5mm headphone, 3.5mm mic, DisplayPort, USB A
Console USB ports quantity	4
Audio connections	Yes
Headphone outputs	5
Number of microphone inputs	5
DC-in jack	Yes

Network

Ethernet LAN	No

Performance

HD type	4K Ultra HD
Maximum resolution	3840 x 2160 pixels
Data transfer rate (max)	0.48 Gbit/s
Scan interval	3,8,15,30 s
Plug and Play	Yes
Daisy chain	No
Number of users	1 user(s)

Design

Rack mounting	Yes
Rack capacity	1U
Product colour	Black
Housing material	Steel
LED indicators	Yes
Hot keys	Yes
Mean time between failures (MTBF)	138327 h
Certification	CE, FCC, TAA, REACH

Display

On Screen Display (OSD)	Yes

Power

Input voltage	100 - 240 V
Input current	0.6 A
Output voltage	12 V
Output current	1.5 A
Power consumption (typical)	18 W
External power adapter	Yes
Power plug type	Type M
Compatible power plug types	AU, EU, JP, UK, US

Sustainability

Compliance certificates	RoHS

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	0 - 40%

Weight & dimensions

Width	131 mm
Depth	220 mm
Height	45 mm
Weight	1 kg

Packaging data

Package width	212 mm
Package depth	409 mm
Package height	87 mm
Package weight	1.6 kg

Packaging content

Quick installation guide	Yes
AC adapter included	Yes
Rubber feet	Yes

Other features

Audio support	Yes
IP control	No

Logistics data

Harmonized System (HS) code	85176200
Master (outer) case width	433 mm
Master (outer) case length	545 mm
Master (outer) case height	258 mm
Products per master (outer) case	6 pc(s)
