Startech 4K HDMI over Fiber Extender Kit, 4K 60Hz up to 3300ft/1km (Single Mode) or 1000ft/300m (Multimode) LC Fiber Optic, HDR/HDCP, Audio/RS232/IR Extender, HDMI Video Extender - Transmitter and Receiver Kit (ST121HD20FXA2) - Video/audio/infrared/network extender - HDMI - over fibre optic - fibre optic - up to 1 km

Description

Manufacturer Code: ST121HD20FXA2

Overview

Startech 4K HDMI over Fiber Extender Kit, 4K 60Hz up to 3300ft/1km (Single Mode) or 1000ft/300m (Multimode) LC Fiber Optic, HDR/HDCP, Audio/RS232/IR Extender, HDMI Video Extender - Transmitter and Receiver Kit (ST121HD20FXA2) - Video/audio/infrared/networ is available through DCS Components. It sits within the Display Cables & Adapters category.

Key product details

• Transmitter and Receiver Kit (ST121HD20FXA2)
• Video/audio/infrared/networ

Procurement and setup support

Available for quote while live availability remains in stock. DCS can help with procurement, compatibility checks, configuration planning, installation support and long-term managed IT lifecycle support.

EAN: 0065030897303

Specifications

Features

Type	AV transmitter & receiver
Maximum resolution	4096 x 2160 pixels
Maximum transfer distance	1000 m
Chipset	SiFotonics SD1503/SD1513
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
Maximum refresh rate	60 Hz
Fiber mode structure	Multi-mode, Single-mode
Extended display identification data (EDID)	Yes
Audio output channels	7.1 channels
Electrostatic Discharge (ESD) protection	Yes
Electrostatic Discharge (ESD) protection	8 kV
Infrared (IR) frequency range	20 - 60 kHz
LED indicators	Activity, Power
Bandwidth	18 Gbit/s
HDCP	Yes
Baud rate	115.2 Kbit/s
HDCP version	2.2
Product colour	Black

Ports & interfaces

Connectivity technology	Wired
HDMI in	1
Number of HDMI outputs	2
HDMI version	2.1
Fiber optic connector	LC
Fiber ports quantity	2
USB ports quantity	2
USB connector type	Micro-USB B
Serial ports quantity	2
Serial interface type	RS-232
Remote (IR) input	2
Remote (IR) output	2
Line outputs (RCA)	1
Line-in	Yes
DC-in jack	Yes

Power

AC input voltage	100 - 240 V
Operating voltage	5 V
Input current	0.35 A
Output current	1 A
Power plug type	Type M

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 90%

Weight & dimensions

Width	68 mm
Depth	134 mm
Height	18 mm
Weight	280 g

Packaging data

Package width	200 mm
Package depth	300 mm
Package height	60 mm
Package weight	1 kg

Packaging content

AC adapter included	Yes
Quick start guide	Yes
IR blaster included	Yes
IR receiver included	Yes

Technical details

Sustainability compliance	Yes
Compliance certificates	CE, RoHS

Logistics data

Master (outer) case width	325 mm
Master (outer) case length	530 mm
Master (outer) case height	402 mm
Products per master (outer) case	20 pc(s)
