Startech 5-Port Ethernet Switch - 10/100Mbps Industrial Networking Solution - IP30-rated Energy Efficient Internet Switch (IES5102) - Switch - unmanaged - 5 x 10/100 - DIN rail mountable - for P/N: NETRS2322P

Description

Manufacturer Code: IES5102

Overview

Startech 5-Port Ethernet Switch - 10/100Mbps Industrial Networking Solution - IP30-rated Energy Efficient Internet Switch (IES5102) - Switch - unmanaged - 5 x 10/100 - DIN rail mountable - for P/N: NETRS2322P is available through DCS Components. It sits within the Managed Switches category.

Key product details

• 10/100Mbps Industrial Networking Solution
• IP30-rated Energy Efficient Internet Switch (IES5102)
• Switch
• unmanaged
• 5 x 10/100

Procurement and setup support

Available for quote while live availability remains in stock. DCS can help with procurement, compatibility checks, configuration planning, installation support and long-term managed IT lifecycle support.

EAN: 0065030859745

Specifications

Management features

Switch type	Unmanaged
Quality of Service (QoS) support	Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)

Network

Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u
10G support	No
Full duplex	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes

Data transmission

Store-and-forward	Yes
Jumbo frames support	No

Design

Rack mounting	Yes
Product colour	Black
Housing material	Plastic
LED indicators	Activity, Link, Power
International Protection (IP) code	IP30
Regulatory Approvals	EN61000-6-2, EN61000-6-4, EN61000-4-3, EN61000-4-4, EN61000-4-6, EN61000-4-8, IEC60068-2-6 Fc, IEC60068-2-27 Ea

Performance

Maximum cable length	100 m
Buffer size	56 KB
Maximum data transfer rate	200 Mbit/s
Mean time between failures (MTBF)	1179133 h

Power

Input voltage	12 - 48 V
Power consumption (max)	2.12 W

Operational conditions

Operating temperature (T-T)	-10 - 60 °C
Storage temperature (T-T)	-25 - 85 °C
Operating relative humidity (H-H)	5 - 95%

Weight & dimensions

Width	25 mm
Depth	70 mm
Height	110 mm
Weight	148 g

Packaging content

Manual	Yes

Packaging data

Terminal block included	Yes
Package width	178 mm
Package depth	198 mm
Package height	79 mm
Package weight	312 g

Certificates

Certification	CE, FCC

Logistics data

Harmonized System (HS) code	85176990
