Startech HDMI KVM Extender over IP Network - 4K 30Hz HDMI and USB over IP LAN or Cat5e/Cat6 Ethernet (100m/330ft) - Remote KVM Console - Video/audio extender - HDMI - up to 100 km - TAA Compliant

Description

Manufacturer Code: SV565HDIP

Overview

Startech HDMI KVM Extender over IP Network - 4K 30Hz HDMI and USB over IP LAN or Cat5e/Cat6 Ethernet (100m/330ft) - Remote KVM Console - Video/audio extender - HDMI - up to 100 km - TAA Compliant is available through DCS Components. It sits within the KVM Switches, Cables & Accessories category.

Key product details

• 4K 30Hz HDMI and USB over IP LAN or Cat5e/Cat6 Ethernet (100m/330ft)
• Remote KVM Console
• Video/audio extender
• HDMI
• up to 100 km

Procurement and setup support

Available for quote while live availability remains in stock. DCS can help with procurement, compatibility checks, configuration planning, installation support and long-term managed IT lifecycle support.

EAN: 0065030877947

Specifications

Ports & interfaces

Keyboard port type	USB
Mouse port type	USB
Video port type	HDMI
HDMI ports quantity	2
USB hub	Yes
USB 2.0 Type-A hub ports quantity	2
Audio connections	Yes
Headphone outputs	8
Number of microphone inputs	2
DC-in jack	Yes

Network

Ethernet LAN (RJ-45) ports	2

Performance

HD type	4K Ultra HD
Maximum resolution	3840 x 2160 pixels
Video bandwidth	30 Hz
Daisy chain	No
Maximum operating distance	100 m
Chipset	ASPEED - AST1520
Audio channels	7.1

Design

Product colour	Black
Housing material	Steel
LED indicators	Yes
Hot keys	No
Mean time between failures (MTBF)	60000 h
Certification	CE, FCC, TAA, REACH

Display

Built-in display	No
On Screen Display (OSD)	Yes

Power

Input voltage	100 - 240 V
Input current	0.6 A
Output voltage	12 V
Output current	1.5 A
Power consumption (typical)	18 W
External power adapter	Yes
Power plug type	Type M
Compatible power plug types	AU, EU, JP, UK

Sustainability

Compliance certificates	RoHS

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	0 - 80%

Weight & dimensions

Width	117 mm
Depth	130 mm
Height	28 mm
Weight	610 g

Packaging data

Package width	365 mm
Package depth	195 mm
Package height	235 mm

Packaging content

Cables included	HDMI, LAN (RJ-45), Phone (RJ-11), USB
Quick installation guide	Yes
AC adapter included	Yes
Rubber feet	Yes

Other features

IP control	No

Logistics data

Harmonized System (HS) code	85176200
Master (outer) case width	385 mm
Master (outer) case length	495 mm
Master (outer) case height	265 mm
Products per master (outer) case	6 pc(s)
