TP-Link Archer T4E AC1200 Wi-Fi and Bluetooth 5.0 PCI Express Adapter

Description

High Speed Dual-Band Wi-Fi
Up to 1200 Mbps Wi-Fi speeds (867 Mbps on 5 GHz band and 300 Mbps on 2.4 GHz band).

Broad Wireless Range
Two external antennas ensure greater Wi-Fi coverage and enhanced stability.

Bluetooth 5.0 Compatible
Ensures a strong and stable wireless connection between your PC and Bluetooth devices.

Improved Security
The latest security enhancement, WPA3, provides enhanced protection in personal password safety.

Plug and Play
Easy setup with the included CD or built-in driver, fully compatible with Windows 11/10.

Beamforming
Wi-Fi signals are strengthened towards certain direction where client exists.

Multiple-Size Brackets
Low profile and full height brackets are both provided, suitable for all PC.

2x2 MIMO
Users can easily access a high-speed wireless connection

802.11ac — Dual Band Wi-Fi for Faster Connections
Archer T4E supports the advanced Wi-Fi standard of IEEE 802.11ac, offering 3 times transferring rates as IEEE 802.11n. You can send emails and browse the web with 2.4GHz network, while keeping the speedy 5GHz band free for gaming, HD streaming and other bandwidth intensive applications.

Bluetooth 5.0 Compatible
Archer T4E equips your PC with Bluetooth 5.0 technology that runs faster connection speeds and farther range, ensuring a strong and stable wireless connection between your PC and Bluetooth devices.

External Antennas for More Targeted Signal
With two external antennas, the Archer T4E ensures extended range and stronger signal strength for reliable, high-speed connectivity in diverse environments.

Precision Manufacturing for Unmatched Performance
Featuring a heatsink for enhanced stability under intensive heat, and premium craftsmanship with oxidation-resistant gold-plated contacts. Together ensuring reliable performance and lasting durability.

Advanced Security
The latest Wi-Fi security protocol, WPA3, brings new capabilities to improve cybersecurity. More secure encryption in Wi-Fi password safety and enhanced protection against brute-force attacks combine to safeguard your home Wi-Fi.

Specifications

Interface
PCI Express, F_USB

Dimensions ( W x D x H)
4.76 x 3.09 x 0.85 in (120.8 x 78.5 x 21.5 mm)

Antenna
2 Dual Band Detachable Antennas

Standards and Protocols
Bluetooth 5.0, Bluetooth 4.2, Bluetooth 4.0

Wireless Standards
IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/g/b 2.4 GHz

Signal Rate
5 GHz
11ac: Up to 867 Mbps(dynamic)
11n: Up to 300 Mbps(dynamic)
11a: Up to 54 Mbps(dynamic)

2.4 GHz
11n: Up to 300 Mbps(dynamic)
11g: Up to 54 Mbps(dynamic)
11b: Up to 11 Mbps(dynamic)

Reception Sensitivity
5 GHz :
11ac HT80 MCS9 -65dBm
11ac HT80 MCS0 -90dBm
11ac HT20 MCS8 -74dBm
11ac HT20 MCS0 -95dBm

2.4 GHz :
11n HT40 MCS7 -72dBm
11n HT40 MCS0 -92dBm
11n HT20 MCS7 -76dBm
11n HT20 MCS0 -94dBm

Wireless Modes
Infrastructure mode

Wireless Security
WEP, WPA/WPA2/WPA3, WPA-PSK/WPA2-PSK

Modulation Technology
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM

Transmission Power
5 GHz: 28dBm(FCC) / 23dBm(CE) (EIRP),
2.4 GHz : 24dBm(FCC) / 20dBm(CE) (EIRP)

Certification
CE, FCC, RoHS

System Requirements
Windows 11/10

Package Content
AC1200 Wi-Fi Bluetooth PCIe Adapter Archer T4E
Two High Gain Dual-Band Antennas
Low-Profile Bracket
Bluetooth Header Cable
Quick Installation Guide
Resource CD

Key Features

• Internal/External: Internal
• Speed: AC1200
• High-Gain Antenna: No

Category: Networking

Manufacturer Code: ARCHER T4E

EAN: 1210002602426

Weight (KG): 0.3

VAT Rate: 20%
