NETGEAR GS748PP - Switch - unmanaged - 24 x 10/100/1000 + 24 x 10/100/1000 (PoE+) - desktop, wall-mountable - PoE+ (380 W)

Description

Manufacturer Code: GS748PP-100EUS

Overview

NETGEAR GS748PP - Switch - unmanaged - 24 x 10/100/1000 + 24 x 10/100/1000 (PoE+) - desktop, wall-mountable - PoE+ (380 W) is available through DCS Components. It sits within the Hubs & Switches category.

Key product details

• Switch
• unmanaged
• 24 x 10/100/1000 + 24 x 10/100/1000 (PoE+)
• desktop, wall-mountable
• PoE+ (380 W)

Procurement and setup support

Available for quote while live availability remains in stock. DCS can help with procurement, compatibility checks, configuration planning, installation support and long-term managed IT lifecycle support.

EAN: 606449174915

Specifications

Management features

Switch type	Unmanaged
Quality of Service (QoS) support	Yes
MIB support	RFC 1213 MIB II, RFC 1643, RFC 1493

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)

Network

Networking standards	IEEE 802.1p, IEEE 802.3az
Copper ethernet cabling technology	10BASE-T
Full duplex	Yes
Flow control support	Yes
Link aggregation	Yes
Ethernet LAN data rates	1000 Mbit/s

Data transmission

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Jumbo frames support	Yes
Jumbo frames	12.288
Packet buffer memory	1.5 MB

Design

Rack mounting	Yes
Product colour	Grey
Redundant fans support	Yes
Number of fans	2 fan(s)
Safety	CE mark, cUL IEC950/EN60950

Performance

Mean time between failures (MTBF)	570972 h

Power

Power source	AC/DC
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	8 A
Power consumption (max)	410 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	380 W

Other features

Latency	2,900ns
Connectivity technology	Wired
Bandwidth	96 Gbit/s
I/O ports	48 x 10/100/1000 Mbps 4 x SFP
Electromagnetic emissions	CE mark, FCC Part 15 Class A, VCCI Class A, C-Tick
Authentication method	802.1x
Warranty period	2 year(s)

Operational conditions

Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Operating altitude	0 - 3000 m
Heat dissipation	34.2 BTU/h

Weight & dimensions

Width	440 mm
Depth	310 mm
Height	43 mm
Weight	4.6 kg

Certificates

Compliance certificates	CB, CE, Federal Communications Commission (FCC), KC, Low Voltage Directive (LVD), RCM, UL, VCCI
