Startech Dual-Laptop USB-C KVM Docking Station, Dual Monitor 4K 60Hz DisplayPort Dock, 5-Port USB Hub, GbE, 90W/45W Power Delivery to Two Laptops, Windows/Mac, 2-Host KVM Dock - Docking station - USB-C 3.2 Gen 2 - 2 x DP - 1GbE - TAA Compliant - United Kingdom, Europe

Description

Manufacturer Code: 129UE-USBC-KVM-DOCK

Overview

Startech Dual-Laptop USB-C KVM Docking Station, Dual Monitor 4K 60Hz DisplayPort Dock, 5-Port USB Hub, GbE, 90W/45W Power Delivery to Two Laptops, Windows/Mac, 2-Host KVM Dock - Docking station - USB-C 3.2 Gen 2 - 2 x DP - 1GbE - TAA Compliant - United Ki is available through DCS Components. It sits within the Docking Stations category.

Key product details

• Docking station
• USB-C 3.2 Gen 2
• 2 x DP
• 1GbE
• TAA Compliant

Procurement and setup support

Available for quote while live availability remains in stock. DCS can help with procurement, compatibility checks, configuration planning, installation support and long-term managed IT lifecycle support.

EAN: 0065030898492

Specifications

Ports & interfaces

Number of computers controlled	2
Keyboard port type	USB
Mouse port type	USB
Video port type	DisplayPort
DisplayPorts quantity	2
DisplayPort version	1.4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
Audio connections	Yes
Headphone outputs	1
Number of microphone inputs	1
DC-in jack	Yes

Network

Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	1
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u

Performance

HD type	4K Ultra HD
Maximum resolution	3840 x 2160 pixels
Chipset	DisplayLink - DL6950, Genesys Logic - GL3590, Genesys Logic - GL9510, Parade - PS186, Realtek - RTL8211F

Design

Product colour	Silver
Housing material	Plastic
LED indicators	LAN, Power
Cable lock slot	Yes

Display

Built-in display	No

Power

Input voltage	100 - 240 V
Input current	2.4 A
Output voltage	20 V
Output current	9 A
Power consumption (typical)	180 W
External power adapter	Yes
Compatible power plug types	EU, UK
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	90 W

System requirements

Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64
Linux operating systems supported	Ubuntu 18.04 LTS, Ubuntu 20.04 LTS, Ubuntu 22.04
Mac operating systems supported	Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Other operating systems supported	ChromeOS

Sustainability

Sustainability compliance	Yes
Compliance certificates	RoHS

Operational conditions

Operating temperature (T-T)	-10 - 45 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 90%

Weight & dimensions

Width	90 mm
Depth	224 mm
Height	40 mm
Weight	402 g

Packaging data

Package width	160 mm
Package depth	285 mm
Package height	90 mm
Package weight	1.8 kg

Packaging content

Cables included	AC, USB Type-C
Quick installation guide	Yes
AC adapter included	Yes

Logistics data

Master (outer) case width	395 mm
Master (outer) case length	380 mm
Master (outer) case height	340 mm
Products per master (outer) case	6 pc(s)
