TP-Link Omada EAP725-Outdoor V1 - Radio access point - 1GbE, 2.5GbE, Wi-Fi 7 - Bluetooth, Wi-Fi 7 - 2.4 GHz, 5 GHz - cloud-managed - wall / pole mountable

Description

Manufacturer Code: EAP725-OUTDOOR

Overview

TP-Link Omada EAP725-Outdoor V1 - Radio access point - 1GbE, 2.5GbE, Wi-Fi 7 - Bluetooth, Wi-Fi 7 - 2.4 GHz, 5 GHz - cloud-managed - wall / pole mountable is available through DCS Components. It sits within the Wireless Access Points category.

Key product details

• Radio access point
• 1GbE, 2.5GbE, Wi-Fi 7
• Bluetooth, Wi-Fi 7
• 2.4 GHz, 5 GHz
• cloud-managed

Procurement and setup support

Available for quote while live availability remains in stock. DCS can help with procurement, compatibility checks, configuration planning, installation support and long-term managed IT lifecycle support.

EAN: 1210002611008

Specifications

Features

2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Maximum data transfer rate	5000 Mbit/s
Maximum data transfer rate (2.4 GHz)	688 Mbit/s
Maximum data transfer rate (5 GHz)	4324 Mbit/s
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1x, IEEE 802.3at
Cabling technology	10/100/1000/2500Base-T
Bluetooth	Yes
Bluetooth version	5.2
Bluetooth Low Energy (BLE)	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
VLAN support	Yes
Virtual LAN features	Management VLAN
Rate limiting	Yes
Wireless isolation	Yes
Band steering	Yes
Quality of Service (QoS) support	Yes
BeamForming	Yes

Security

Security algorithms	OWE, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
MAC address filtering	Yes
Service Set Identifier (SSID) features	Multiple SSIDs
Number of SSID supported	16
Schedule access	Yes

Management features

Web-based management	Yes
Syslog	Yes
Cloud-managed	Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports	1

Power

Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	PoE+
Power consumption (max)	18.4 W

Design

Placement	Pole, Wall
Product colour	White
International Protection (IP) code	IP66
Reset button	Yes
LED indicators	Status

Antenna

Antenna type	Internal & external
Antennas quantity	8
Antenna gain level (max)	13.2 dBi

Certificates

Compliance certificates	BSMI, CE, Federal Communications Commission (FCC), Industry Canada (IC), JRF, NCC, RoHS, VCCI

Weight & dimensions

Width	208 mm
Depth	160 mm
Height	55 mm
Weight	1.33 kg

Packaging content

Quantity per pack	1 pc(s)
Mounting kit	Yes

Operational conditions

Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-30 - 70 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
