TP-Link UH5020C V1 - Docking station - for desktop, laptop, smartphone, tablet - USB-C - HDMI

Description

5 in 1 USB-C Hub
UH5020C turns a single USB-C port into 5 ports with a 4K@60Hz HDMI, 100W Power Delivery, 1× USB-C Data Port, 2× USB-A Data Ports.

Ultra High-Definition Media Display
Connect to an external monitor via the 4K@60Hz HDMI port for a stunning ultra high-definition experience.

Powerful 100W Fast Charging
Plug the charging cable into UH5020C and continuously deliver up to 100W of power to your PC while transferring files or streaming media.

5 Gbps SuperSpeed Data Transfer
UH5020C adds three USB 3.0 ports to your device, enabling simultaneous use of multiple USB devices.

Easy to Use with Plug & Play
Simply plug in and start using in seconds, thanks to driver-free install with Mac OS, Windows 11/10/8.1/8/7, Linux OS, iPadOS, iOS, Android, Chrome OS, and Nintendo OS.

Compact and Elegant Design
The self-storing design not only protects the connector, but also but also improves portability. Aluminum alloy case and braided cable make UH5020C more durable. Bring you a better user experience.

Specifications

Ports & interfaces

Host interface	USB Type-C
Hub interfaces	HDMI, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	2
HDMI ports quantity	1
Ports quantity	5
Card reader integrated	No
DC-in jack	No

Features

Data transfer rate	5000 Mbit/s
Maximum refresh rate	60 Hz
Supported video modes	2160p
Maximum resolution (HDMI)	4096 x 2160 pixels
Product colour	Grey
Housing material	Aluminium
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	100 W
Fast charging	Yes
Cable type	Round cable
Cable length	0.18 m
Plug and Play	Yes
Certification	HDMI

Power

Power supply type	USB

System requirements

Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Mac operating systems supported	MacOS
Linux operating systems supported	Yes
Other operating systems supported	Android, ChromeOS, iOS, iPadOS
Compatible operating systems	Nintendo OS

Weight & dimensions

Width	108.2 mm
Depth	40 mm
Height	12.2 mm

Packaging data

Quantity per pack	1 pc(s)
Package type	Hanging box

Packaging content

Quick start guide	Yes

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%

Design

Cable colour	Black

Technical details

Compliance certificates	BSMI, CE, EAC, Federal Communications Commission (FCC), RoHS, UKCA
